Applications: Install in the clean room system terminal hepa box
Specification
Frame: Aluminum alloy. Galvanized sheet metal; Filter material: Glass fiber filter paper
Filter Material separation: Paper ; Aluminum foil.
Efficiency:
H14(EN 1822): 99.995% at MPPS (0.3um)
Temperature:≤80o C
Humidity:≤80% RH
Recommended final pressure drop: ≤580 Pa
Model No. | Actual Size (mm) | Filtration area （m2） | Air flow /initial resistance （m3/h / Pa） | Efficiency EN1822 | ||
Length | Width | Thickness | ||||
DMAI-H-P637 | 320 | 320 | 150 | 2.9 | 250 / 210 | H14 |
DMAI-H-P638 | 484 | 484 | 150 | 8.2 | 450 /210 | H14 |
DMAI-H-P639 | 610 | 610 | 150 | 11.8 | 850 /210 | H14 |
DMAI-H-P640 | 630 | 630 | 150 | 14.5 | 1000/210 | H14 |
DMAI-H-P641 | 762 | 610 | 150 | 18.6 | 1500 /210 | H14 |
DMAI-H-P642 | 915 | 610 | 150 | 19.4 | 1800 /210 | H14 |
DMAI-H-P643 | 1220 | 610 | 150 | 26.5 | 2000 /210 | H14 |
DMAI-H-P644 | 1260 | 630 | 150 | 28.8 | 2350 /210 | H14 |
DMAI-H-P645 | 320 | 320 | 220 | 7.2 | 400 / 210 | H14 |
DMAI-H-P646 | 484 | 484 | 220 | 13.4 | 1000/210 | H14 |
DMAI-H-P647 | 610 | 610 | 220 | 15.2 | 1650 /210 | H14 |
DMAI-H-P648 | 630 | 630 | 220 | 18.6 | 2500 /210 | H14 |
DMAI-H-P649 | 762 | 610 | 220 | 23.9 | 2000 /210 | H14 |
DMAI-H-P650 | 915 | 610 | 220 | 27.5 | 1250 /210 | H14 |
DMAI-H-P651 | 1220 | 610 | 220 | 32.5 | 2500/ 210 | H14 |
DMAI-H-P652 | 1260 | 630 | 220 | 36.8 | 3000/ 210 | H14 |
DMAI-H-P653 | 968 | 484 | 220 | 18.5 | 2000/ 210 | H14 |
DMAI-H-P654 | 762 | 484 | 220 | 21.3 | 1500/ 210 | H14 |
